GESCHAKELDE VOEDING 5.0V 10.0A 50W PRINT MONTAGE
€ 23,50
€ 19,42
Artikelnummer
IRM6005
- ArtikelnummerIRM6005
- MerkMEANWELL
- Aantal 3+ € 22,31 € 18,44
Features
| • Enclosed type • IRM-60-_: for PCB mounting • IRM-60-_ST: for screw terminal mounting • Universal input • Protections: short circuit/over load/over voltage • Cooling by free air convection • Low no load power consumption • Insulation class II |
 |
| Technical Specifications |
|
|
| Input Voltage: | 85...264V AC (47...440Hz) |
| Input Inrush Current, Max.: | 60A |
| No Load Power Consumption, Max.: | 0,1W |
| Withstand Voltage: | 3000V AC |
| Operating Temperature: | -30...+70°C |
| Weight | |
| IRM-60-_: | 195g |
| IRM-60-_ST: | 228g |
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| IRM-60-5 | 5 | 0...10 | 50 | 2,5 | 80 | 84 |
| IRM-60-12 | 12 | 0...5 | 60 | 2,5 | 120 | 87,5 |
| IRM-60-15 | 15 | 0...4 | 60 | 2,5 | 120 | 89 |
| IRM-60-24 | 24 | 0...2,5 | 60 | 2,5 | 150 | 90 |
| IRM-60-48 | 48 | 0...1,25 | 60 | 2,5 | 240 | 91 |
| IRM-60-5ST | 5 | 0...10 | 50 | 2,5 | 80 | 84 |
| IRM-60-12ST | 12 | 0...5 | 60 | 2,5 | 120 | 87,5 |
| IRM-60-15ST | 15 | 0...4 | 60 | 2,5 | 120 | 89 |
| IRM-60-24ST | 24 | 0...2,5 | 60 | 2,5 | 150 | 90 |
| IRM-60-48ST | 48 | 0...1,25 | 60 | 2,5 | 240 | 91 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
|
||||||
| Norms |
| TÜV EN60950-1, UL60950-1 |
|
| Approvals |
    |
